| Impact energy |
19 J |
| Impact rate at rated speed |
1,750 – 2,150 bpm |
| Rated speed |
0 – 220 rpm |
Additional data
|
| Rated input power |
1,700 W |
| Weight |
11.9 kg |
| Tool dimensions (width) |
120 mm |
| Tool dimensions (length) |
600 mm |
| Tool dimensions (height) |
312 mm |
| Tool holder |
SDS max |
Drilling range
|
| Drilling dia. concrete, hammer drill bits |
12 – 52 mm |
| Opt. appl. range concrete, hammer drill bits |
30 – 50 mm |
| Drilling dia. concrete, breakthrough drill bits |
80 – 80 mm |
| Drilling diameter in concrete with core cutters |
50 – 150 mm |
Total vibration values (Hammer drilling in concrete)
|
| Vibration emission value ah |
10 m/s² |
| Uncertainty K |
1.5 m/s² |
Total vibration values (Chiselling)
|
| Vibration emission value ah |
8 m/s² |
| Uncertainty K |
1.5 m/s² |
Hammer drilling in concrete
|
| Vibration emission value ah |
10 m/s² |
| Uncertainty K |
1.5 m/s² |
Chiselling
|
| Vibration emission value ah |
8 m/s² |
| Uncertainty K |
1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 109 dB(A); Sound power level 98 dB(A). Uncertainty K= 3 dB.
