Fischer Cantilever arm FCA 21
by Fischer
KES 1,300
KES 1,470
KES 1,730
The fischer cantilever arm FCA allows for quick and easy installation of pipelines along the wall, for example. Simple alignment of console via slots in the base plate that are rotated 90° to face each other.
- Fire inspection report in line with MLAR/EN13501.
- Graduated range of lengths.
- Different hole geometry.
- High installation flexibility.
| UPC | 537207 |
|---|---|
| Model Number | 537207 |
| Profile | 21/ 2.0 |
| Length (mm) | 200 |
| SKU | 537207 |
| UPC | 537208 |
|---|---|
| Model Number | 537208 |
| Profile | 21 / 41 |
| Length (mm) | 300 |
| SKU | 537208 |
| UPC | 537209 |
|---|---|
| Model Number | 537209 |
| SKU | 537209 |
Reviews
This product does not have any reviews yet.
Add your reviewDescription
Advantages
- The arm's solid base plate offers a secure hold for load-bearing construction.
- The base plate's long slots, which are at 90° to one another, allow the arm to be easily aligned.
- The stamped teeth in the channel gives the sliding nuts a secure hold for high shear loads, e.g. for vertical installation.
Properties
- Material: steel S235 JR (material no.10037) acc. to DIN EN 10025
- Zinc plating: electro zinc-plated, min. 10 µm
Applications
- Quick and easy installation of pipelines (e.g. along the wall)
